Method of solution

A fully implicit numerical algorithm is used that allows both Newton-like iterations to steady state and time-dependent solutions with large time-steps. A preconditioning matrix is obtained by approximate (ILUT) inversion of a numerical finite-difference Jacobian, which is then used in a Newton-Krylov solution algorithm. A finite-volume differencing algorithm is used. Over 95% of the coding is in Fortran with the remainder being C.

Related and auxiliary software

Although UEDGE is written in Fortran, for efficient execution and analysis of results, it utilizes either Python or BASIS scripting shells. Python is easily available for many platforms (http://www.Python.org/). The features and availability of BASIS are described in “Basis Manual Set” by P.F. Dubois, Z.C. Motteler, et al., Lawrence Livermore National Laboratory report UCRL-MA-118541, June, 2002 and http://basis.llnl.gov/), however, BASIS is deprecated. Contact one of the UEDGE developers if you insist on running it within that environment. The Python version of UEDGE uses the same source files but utilizes Forthon to produce a Python-compatible source. Forthon has been developed by D.P. Grote (see http://hifweb.lbl.gov/Forthon/ and Grote et al. in the references below), and it is freely available. The graphics can be performed by any package importable to Python, such as PYGIST. The parallel version of UEDGE available through Python also uses the PETSc linear algebra solver whose development has been led by ANL (https://www.mcs.anl.gov/petsc/).

UEDGE can also be coupled to other codes. An excellent example is couplling to the DUSTT code from UCSD (contact rsmirnov@eng.ucsd.edu) that follows the trajectories and ablation of dust particles in the background UEDGE plasma and provides impurity sources to UEDGE. For an example, see R. Smirnov et al., Phys. Plasmas 22 (2015) 012506.

Authors contributing to V7 release

T.D. Rognlien, I. Joseph, W.H. Meyer, M.E. Rensink, and M.V. Umansky, LLNL
(trognlien@llnl.gov, joseph5@llnl.gov, meyer8@llnl.gov, rensink1@llnl.gov, umansky1@llnl.gov)

Acknowledgements to previous contributors

P.N. Brown, R.H. Cohen, D.P. Grote, A.C. Hindmarsh, L.L. LoDestro, J.L. Milovich, A. Pankin, G.D. Porter, and G.R. Smith, all presently or formerly at LLNL; M. McCourt, L.C. McInnes, and H. Zhang, ANL; J.R. Cary, A.H. Hakim, S.E. Kruger, and A. Pankin, Tech-X; D.A. Knoll, INEEL; D.P. Stotler, PPPL; B.J. Braams, retired, IAEA; A.Yu. Pigarov and R. Smirnov, UCSD; J.D. Elder, U. Toronto; M. Groth, Aalto Univ.; and R.B. Campbell, Sandia.

References

UEDGE development
T.D. Rognlien, J.L. Milovich, M.E. Rensink, and G.D. Porter, J. Nucl. Mat. 196-198 (1992) 347-351.
G.R. Smith, P.N. Brown, R.B. Campbell, D.A. Knoll, P.R. McHugh, M.E. Rensink, and T.D. Rognlien, J. Nucl. Mater. 220-222 (1995) 1024.
M.E. Rensink and T.D. Rognlien, J. Nucl. Mater. 266-269 (1999) 1180.
T.D. Rognlien, D.D. Ryutov, N. Mattor, and G.D. Porter, Phys. Plasmas 6, (1999) 1851.
T.D. Rognlien, M.E. Rensink, and G.R. Smith, “User manual for the UEDGE edge-plasma transport code,” January 2000, LLNL Rpt. UCRL-ID-137121, lastest revision May 1, 2013.

Forthon development D. P. Grote, A. Friedman, I. Haber, “Methods used in WARP3d, a Three-Dimensional PIC/Accelerator Code”, Proceedings of the 1996 Computational Accelerator Physics Conference, AIP Conference Proceedings 391, p. 51.
See also: http://hifweb.lbl.gov/Forthon/ .

FACETS project
J.R. Cary, J. Candy, R.H. Cohen et al., J. Phys.: Conf. Ser. 125 (2008) 012040.
A.H. Hakim, T.D. Rognlien, R.J. Groebner et al., Phys. Plasmas 19 (2012) 032505.
M. McCourt, T.D. Rognlien, L.C. McInnes, and H. Zhang, Computational Science & Discovery 5 (2012) 014012.
